gitea-pages/pages/merlin7/03-Slurm-General-Documentation/slurm-examples.md

title, keywords, last_updated, summary, sidebar, permalink

title	keywords	last_updated	summary	sidebar	permalink
Slurm Examples	slurm example, template, examples, templates, running jobs, sbatch, single core based jobs, HT, multithread, no-multithread, mpi, openmp, packed jobs, hands-on, array jobs, gpu	24 Mai 2023	This document shows different template examples for running jobs in the Merlin cluster.	merlin7_sidebar	/merlin7/slurm-examples.html

{:style="display:block; margin-left:auto; margin-right:auto"}

{{site.data.alerts.warning}}The Merlin7 documentation is Work In Progress. Please do not use or rely on this documentation until this becomes official.
This applies to any page under https://hpce.pages.psi.ch/merlin7/ {{site.data.alerts.end}}

Single core based job examples

#!/bin/bash
#SBATCH --partition=hourly      # Using 'hourly' will grant higher priority
#SBATCH --ntasks-per-core=2     # Request the max ntasks be invoked on each core
#SBATCH --hint=multithread      # Use extra threads with in-core multi-threading
#SBATCH --time=00:30:00         # Define max time job will run
#SBATCH --output=myscript.out   # Define your output file
#SBATCH --error=myscript.err    # Define your error file

module purge
module load $MODULE_NAME # where $MODULE_NAME is a software in PModules
srun $MYEXEC             # where $MYEXEC is a path to your binary file

Multi-core based jobs example

Pure MPI

#!/bin/bash
#SBATCH --job-name=purempi
#SBATCH --partition=daily      # Using 'daily' will grant higher priority
#SBATCH --time=24:00:00        # Define max time job will run
#SBATCH --output=%x-%j.out     # Define your output file
#SBATCH --error=%x-%j.err      # Define your error file
#SBATCH --exclusive
#SBATCH --nodes=1
#SBATCH --ntasks=128
#SBATCH --hint=nomultithread
##SBATCH --cpus-per-task=1

module purge
module load $MODULE_NAME # where $MODULE_NAME is a software in PModules
srun $MYEXEC             # where $MYEXEC is a path to your binary file

Hybrid

#!/bin/bash
#SBATCH --job-name=hybrid
#SBATCH --partition=daily      # Using 'daily' will grant higher priority
#SBATCH --time=24:00:00        # Define max time job will run
#SBATCH --output=%x-%j.out     # Define your output file
#SBATCH --error=%x-%j.err      # Define your error file
#SBATCH --exclusive
#SBATCH --nodes=1
#SBATCH --ntasks=128
#SBATCH --hint=multithread
#SBATCH --cpus-per-task=2

module purge
module load $MODULE_NAME # where $MODULE_NAME is a software in PModules
srun $MYEXEC             # where $MYEXEC is a path to your binary file
